Gas Booster Pump: Maximum Gas Outlet Pressure: 1200 BAR / 17,400 PSI

The TEREK GU-GTB-200 is a high-performance gas booster pump designed and manufactured for reliable, high-pressure gas compression. Engineered with a robust structure using aluminum alloy and stainless steel, this pump is capable of handling a wide range of industrial gases, including inert gases like Nitrogen, CO2, Argon, and Helium, as well as flammable and risky gases like Hydrogen, Oxygen, and Natural Gas. This series features a double-driven cylinder, single-stage design with a large 160 mm driven piston for efficient operation.

Key Features

• Robust Construction: Built with high-quality aluminum alloy and stainless steel for durability and long service life.

• Wide Gas Compatibility: Suitable for oil-free compression of industrial, inert, and flammable gases.

• High-Pressure Output: Capable of achieving a maximum outlet pressure of 1200 BAR (17,400 PSI).

• Precise Pressure Control: Offers excellent pressure control accuracy of less than 1% of Full Scale (F.S.).

• Safe and Reliable: Equipped with high-pressure needle valves, stainless steel piping, and a CL 1.6 grade pressure gauge for safe operation.

• Low Noise Operation: Designed to operate at noise levels below 75 dB.

Technical Specifications

• Model: GU-GTB-200

• Pressure Ratio: 200:1

• Maximum Gas Outlet Pressure: 1200 BAR / 17,400 PSI

• Drive Air Pressure Range: 2 - 8 BAR

• Drive Air @ 5.0 BAR: Output Pressure = 1200 BAR / 17,400 PSI

• Drive Air @ 4.5 BAR: Output Pressure = 900 BAR / 13,050 PSI

• Gas Inlet Pressure Range: 35 - 400 BAR (Minimum - Maximum)

• Working Medium: Nitrogen, Helium, or other specified gases.

• Drive Medium: Compressed Air

• Drive Air Inlet Size: 12mm PU Flexible Pipe

• Gas Inlet Connection: NPT 1/4" Internal Thread

• Gas Outlet Connection: NPT 1/4" Internal Thread or 9/16''-18 UNF-2B

• Air Consumption: 0.6 - 0.8 M³/min

• Recommended Air Compressor: 10HP / 7.5KW or 8HP / 6.0KW

• Pressure Measurement Accuracy: CL 1.6 Pressure Gauge

• Noise Level: < 75 dB

• Relative Humidity: < 90%

• Ambient Pressure: 0.1 MPa

Application

This gas booster pump is ideal for various high-pressure gas applications across multiple industries, including:

• Gas cylinder filling and compression.

• Leak testing and pressure testing of components.

• Charging accumulators and hydraulic systems.

• Providing high-pressure gas for research and development laboratories.

• Applications in the energy, aerospace, and manufacturing sectors.

Lystus Technical: Your Trusted Partner

Lystus Technical is the authorized distributor, seller, and supplier for the TEREK range of gas booster pumps. We provide not only top-quality equipment but also comprehensive technical support and after-sales service to ensure optimal performance for your specific applications.

For inquiries and purchases, please contact Lystus Technical.
